1. This self-propelled sprayer features four-wheel drive/four-wheel steering. It is equipped with an 18.38KW single-cylinder water-cooled four-stroke diesel engine, which has a large torque. Low fuel consumption (91.5-2L/h), economical and practical.
2. Ultra-low ground clearance, equipped with 0940mm inflatable wheels or paddy field wheels. When driving on hilly, mountainous and rough roads, the center of gravity is low, making driving safer.
3. We independently designed a 4-speed transmission with both high and low speeds, ensuring a smooth start and smooth acceleration on muddy sections or mountain roads.
4. According to the row and plant spacing of the planted crops, aluminum alloy spray rods and stainless steel nozzles can be optionally equipped. Stainless steel spray rods can also be configured for support according to the ridge spacing of crops, and the water flowing outside the pipe can be independently switched and the spray heads can be fastened. Impact-resistant, collision-proof, and durable.
5. The length of the spray rod can be selected as 6m, 9m or 10m. Hydraulic lifting and folding of the spray rod; When encountering obstacles such as trees during the new work process, the height or position of the spray boom can be easily adjusted to smoothly avoid the obstacles.
6. The medicine box is equipped with reflux stirring and jet stirring to make the mixture of the medicine liquid more uniform and improve the prevention and control effect.
1. Weeding, pest and disease control, and foliar fertilizer spraying during the cultivation process of field food crops; Pest, disease and weed control, and foliar fertilizer spraying operations for large-scale cultivation of soybeans, cotton, vegetables, etc.
2. The front spray rod is used for spraying liquid medicine, and the rear centrifugal fertilizer sprayer is used for spreading granular fertilizer. Dual-purpose in one machine.
3. It is particularly suitable for rice-growing areas, with strong passability and low seedling rolling rate.
4. It can be optionally equipped with a hanging spray mechanism and is suitable for pesticide spraying operations on tobacco, shrubs and fruit trees.
5. Spraying of hygiene and epidemic prevention disinfectants in public places.
1. According to the refueling standards: Add diesel to the diesel tank, pure water to the radiator, and diesel engine oil to the engine.
2. According to the dilution standard of the medicine, add the medicine to the mixer and pour clean water into the medicine tank to ensure uniform mixing.
3. Turn on the power, press the accelerator key clockwise, gently step on the accelerator, start in low gear 1, and gradually accelerate to high gear to move forward.
4. Pull the handle for lifting and extending the spray rod to adjust its height to 500mm from the top of the crop.
5. Step on the clutch, push the pump clutch handle to the engaged position, increase the throttle to speed up the operation of the drug pump, and rotate the pressure regulating handle clockwise to adjust the water pressure to 0.5 mpa.
